48W (24V2A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 1A max@115Vac/0.5A max.@230Vac input
No-Load Consumption: 0.5W max.@115Vac/230Vac
Rated Output: DC24V, 2A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 120mVp-p
Certifications: UL, CE, FCC, CB, BIS
48W (12V4A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 2A max@115Vac/1A max.@230Vac input
No-Load Consumption: 0.5W max.@115Vac/230Vac
Rated Output: DC12V, 4A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 120mVp-p
Certifications: UL, CE, FCC, CB, BIS
36W (24V1.5A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 1A max@115Vac/0.5A max.@230Vac input
No-Load Consumption: 0.5W max.@115Vac/230Vac
Rated Output: DC24V, 1.5A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 120mVp-p
Certifications: UL, CE, FCC, CB, BIS
36W (12V3A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 1A max@115Vac/0.5A max.@230Vac input
No-Load Consumption: 0.5W max.@115Vac/230Vac
Rated Output: DC12V, 3A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 120mVp-p
Certifications: UL, CE, FCC, CB, BIS
30W (12V2.5A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 1A max@115Vac/0.5A max.@230Vac input
No-Load Consumption: 0.5W max.@115Vac/230Vac
Rated Output: DC12V, 2.5A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 120mVp-p
Certifications: UL, CE, FCC, CB, BIS
18W (5V3.6A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 0.6A max@115Vac/0.3A max.@230Vac input
No-Load Consumption: 0.3W max.@115Vac/230Vac
Rated Output: DC5V, 3.6A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 120mVp-p
Certifications: UL, CE, FCC, CB, BIS
18W (12V1.5A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 0.6A max@115Vac/0.3A max.@230Vac input
No-Load Consumption: 0.3W max.@115Vac/230Vac
Rated Output: DC12V, 1.5A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 120mVp-p
Certifications: UL, CE, FCC, CB, BIS
12W (12V1A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 0.5A max@115Vac/0.3A max.@230Vac input
No-Load Consumption: 0.3W max.@115Vac/230Vac
Rated Output: DC12V, 1A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 100mVp-p
Certifications: UL, CE, FCC, CB, BIS
12W (12V1A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 0.5A max@115Vac/0.3A max.@230Vac input
No-Load Consumption: 0.3W max.@115Vac/230Vac
Rated Output: DC12V, 1A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 100mVp-p
Certifications: UL, CE, FCC, CB, BIS
12W (5V2.4A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 0.5A max@115Vac/0.3A max.@230Vac input
No-Load Consumption: 0.3W max.@115Vac/230Vac
Rated Output: DC5V, 2.4A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 100mVp-p
Certifications: UL, CE, FCC, CB, BIS
6W (12V0.5A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 0.3A max@115Vac/0.15A max.@230Vac input
No-Load Consumption: 0.3W max.@115Vac/230Vac
Rated Output: DC12V, 0.5A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 100mVp-p
Certifications: UL, CE, FCC, CB, BIS
6W (5V1.2A)Specifications:
Input Voltage range: AC90V~264V, 47~63Hz
Input Current: 0.3A max@115Vac/0.15A max.@230Vac input
No-Load Consumption: 0.3W max.@115Vac/230Vac
Rated Output: DC5V, 1.2A
Line Regulation: ±3%
Load Regulation: ±5%
Output voltage ripple and noise: 100mVp-p
Certifications: UL, CE, FCC, CB, BIS
