Product Introduction

By installing a pair of 5GHz WiFi antennas at the top of the elevator shaft to cover the elevator shaft. It can support Ethernet expansion to achieve a one-to-four networking configuration, covering four elevators. The near end integrates a 5GHz WiFi bridge and router with ONU (optional) function.

13651816436 Manager Sheng

Tel

Product Specifications

Network Cable Expansion Antenna Specification Parameters:
Interface: 2100M Ethernet interfaces
Modulation: BPSK/QPSK/16QAM/64QAM
Return path protocol: TDMA
Frequency band: 5180~5320MHz, 5745~5825MHz (China)
Maximum power: 2125mw
Channel bandwidth: 10/20/40MHz
Operating mode: Access point, WDS access point
Security configuration: WPA2-PSK, hidden SSID, IP/MAC filtering
Return path bandwidth: Supports 2m-300m pull-out coverage, system throughput >90Mbps
Gain: ≥12dBi
Return path antenna: Supports 2*2MIMO built-in antenna
Power supply mode: Passive POE
Installation method: Ceiling mounted, bracket mounted
Network Cable Expansion Near End Parameters:
Ethernet interface: 1 10/100/1000Mbps WAN, 4 10/100Mbps LAN
Antenna: 2.4GHz: built-in antenna
Buttons: Reset Button *1 factory reset
Operating mode: WAN mode: DHCP, PPPoE, static (fixed IP)
